ATCO

ATCO LINER 22 SH V Walk behind

ATCO LINER 22 SH V Walk behind

£782.50 + VAT (£939.00)
+ VAT (£0.00) £782.50 + VAT (£939.00)
Special Offer Sold out
Shipping calculated at checkout.

294569037/AT1

Available to Order (Subject to Manufacturer Availability)

Oversized Shipping Rates Apply

View our shipping policy here

The Liner 22SHV is powered by a Honda GCVx170 Autochoke OHV engine, offering smooth starts, efficient fuel economy, and the kind of high-quality simplicity that Honda engine fans know and love.

With powerful self-propulsion, the Liner 22SHV easily handles slopes, rough patches, and tussocky grass.

The four-edged Twinclip blade cuts and recuts the grass clippings, allowing the Liner 22SHV to pack up to 20% more grass into its extra-large 80-litre collector.

With a hybrid galvanised steel/aluminium cutter deck, the Liner 22SHV is designed for strength and durability.

With a 53cm cutting width, front skid plate, and an extra-low cutting height (down to 13mm), the Liner 22SHV delivers an outstanding striped finish every time.

Features

Variable Speed Control:

  • Adjust the mowing speed to match your pace, making every pass comfortable and efficient.

Full-Width Steel Rear Roller:

  • Create a stunning, professional striped finish with the quality steel full-length rear roller.

Twinclip Blade for a Precise Cut:

  • The twinclip blade design cuts grass twice in a single pass, ensuring a cleaner, sharper finish.

Specifications

Power:

  • Power source: Petrol
  • Power: 3.3 kW
  • Engine Brand: Honda
  • Engine model: GCVx170 OHV Autochoke
  • Displacement: 167 cm³
  • Engine rotation speed: 2900 rpm
  • RPM control: Fixed rpm
  • Starter: Recoil
  • Engine Oil tank capacity: 0.4 l
  • Fuel tank capacity: 0.95 l
  • Mowing area: 1000 m²

Cutting System:

  • Deck material: Galvanised steel
  • Cutting width: 53 cm
  • Cutting height adjustment: Centralized
  • Cutting height positions: 8 positions
  • Cutting height range: 13 - 65 mm

Drive System:

  • Driving: Self-propelled with speed variator
  • Traction: Rear-roller drive
  • Speed forward: 3 - 4.9 km/h

Equipment:

  • Collector capacity: 80 l
  • Handlebar type: Ergonomic 25 mm adj. by button + soft grip
  • Wheels: 200/ROLLER grooved wheels on ball bearings
  • Vibe Control System (VCS): Yes
  • Front handle: Yes
  • Adjustable handlebar: Yes
  • Foldable handlebar: Yes
  • Washing link: Yes
  • Collector type: Textile

Vibration and Noise Data:

  • Guaranteed sound power level (LwA): 98 dB(A)
  • Measured sound power level: 98 dB(A)
  • Measured sound pressure level at operator ear: 86 DB(A)
  • Vibration level hand: 8 m/s²

Overall Dimensions:

  • Pack weight: 53.04 kg
  • Product length: 1680 mm
  • Product width: 560 mm
  • Product height: 1100 mm
  • Weight: 47 kg
