Thanks to its low centre of gravity design, the 825D remains stable on all types of terrain and offers the operator excellent visibility and manoeuvrability.

The driving position located above the rear wheels allows greater control of the vehicle.
In addition, the silent-block system if lifts the cab from the chassis allows the operator to avoid violent shocks and vibrations.

Features
  • Lifting with Counterweights: 1300kg
  • Engine Power (Kubota D722): 26HP
  • Hydraulic Flow Rate: 42L/min Hydrostatic Pump
  • Boom Length: 2980mm Telescopic
Specifications
  • Engine: Kubota D 1105
  • Power: 25 Hp / 18.6 Kw
  • Hydrostatic transmission - 4WD: Standard
  • Electric differential lock: Standard
  • Water cooling: Standard
  • Self Levelling: Standard
  • Hydraulic system: 42 L/min
  • Joystick: 11 - function
  • 12 V power outlet + front auxiliary electric outlet (165 W): Standard
  • Working LED lights (2 front + 1 rear): Standard
  • Adjustable ergonomic seat with belts: Standard
  • “UNIVERSAL” coupling plate: Standard
  • Metal hoods: Standard
  • ROPS+FOPS protection: Standard
  • Telescopic boom: Standard
  • Silent block: Standard
  • Tractor wheels: 23x10.50-12
  • Weight: 1315 kg
  • Tipping load in transport position: 950 kg
  • Max pulling force: 800 kg (@ 23x8.50-12)
  • Breakout force with boom down: 980 kg
  • Average sound power level: 99 dB/LwA
  • Guaranteed sound power level: 101 dB/LwA
  • Speed: 12 km/h
  • Engine oil tank capacity: 5.1 L
  • Hydraulic oil tank capacity: 29 L
