Castloaders 830D Carbon

CAST

Castloaders 830D Carbon

£29,215.00 + VAT (£35,058.00)
Shipping calculated at checkout.
C8300001M1

Oversized Shipping Rates Apply

Available to order

What does this mean?

Available to Order items are ordered directly from the manufacturer. If there are additional delays we will notify you via email.

In-store stock: 0

Once parts arrive, pickup is available at Coed Court

We will contact you once it arrives at our store

View store information

Castloaders 830D Carbon

Coed Court

Pickup available, usually ready in 2-4 days

Coed Court
Treforest Ind. Est.
Pontypridd CF37 5SW
United Kingdom

01443 230000

Click & collect in Treforest

Questions? Call us on 01443 230000

Payment methods
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • JCB
  • Maestro
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

Some of the 830D's features include a heated seat, ergonomic joystick and a telescopic arm that reaches up to 3 metres.

The driving position located above the rear wheels allows greater control of the vehicle. In addition, the silent-block system that lifts the cab from the chassis allows the operator to avoid violent shocks and vibrations.

Features
  • Lifting with Counterweights: 1300kg
  • Engine Power (Kubota D1305): 26HP
  • Hydraulic Flow Rate: 46L/min Hydrostatic Pump
  • Boom Length: 2980mm Telescopic
Specifications
  • Engine: Kubota D 1305
  • Power: 26 Hp / 18.6 Kw
  • Hydrostatic transmission - 4WD: Standard
  • Electric differential lock: Standard
  • Water cooling: Standard
  • Self Levelling: Standard
  • Hydraulic system: 46 L/min
  • Joystick: 11 - function ergonomic joystick
  • 12 V power outlet + front auxiliary electric outlet (165 W): Standard
  • Working LED lights (2 front + 1 rear): Standard
  • Comfort heated seat: Standard
  • “UNIVERSAL” coupling plate: Standard
  • Metal hoods: Standard
  • ROPS+FOPS protection: Standard
  • Telescopic boom: Standard
  • Silent block: Standard
  • Tractor wheels: 26x12.00-12
  • Rear counterweights (100 kg): Standard
  • Weight: 1380 kg
  • Special finishing with sablè paint: Standard
  • Carbon Look dashboard: Standard
  • Tipping load in transport position: 950 kg
  • Max pulling force: 800 kg (@ 23x8.50-12)
  • Breakout force with boom down: 980 kg
  • Average sound power level: 99 dB/LwA
  • Guaranteed sound power level: 101 dB/LwA
  • Speed: 16 km/h
  • Engine oil tank capacity: 5.7 L
  • Hydraulic oil tank capacity: 29 L
