ECHO CS-2511TES Chainsaw

Compact, lightweight and widely considered as the best top handle petrol chainsaw on the market, the ECHO® CS-2511TES top handle saw has become a favourite for the arborist, climbers and foresters from around the world.

The CS-2511TES top handle arborist chainsaw is ECHO’s lightest and most compact saw. Weighing just 2.3kg (dry weight w/o bar and chain) and with an ergonomic compact design, the saw is both highly manoeuvrable and can be used for long periods with little fatigue. At the same time, the engine produces 1.10kW giving the CS-2511TES a superior power-to-weight ratio.

Innovation is the essence of ECHO and although small, the CS-2511TES is packed with innovative features. Grouped controls and a new ergonomic top handle makes the CS-2511TES a great climbing saw. A swing-out lanyard ring is positioned for superior balance and easy climbing.

Specification

Engine displacement (cm³)   25.0

Output (kw)   1.11

Output (ps)   1.51

Dry Weight (kg) (undefined)   2.3

Fuel Tank Capacity (ml)  190

Chain Oil Tank Capacity (ml)   140

Fuel Consumption At Maximum Engine Power (L/h)   0.68

Priming Pump   Yes

Ignition System   CDI

Start Assist System   ES-start

Chain Brake   Inertia

Choke w/ Automatic Fast Idle Release   Yes

Chain Tensioner   Side

Saw Chain Pitch (inch)   3/8

Guide Bar Gauge (inch)   0.50

Applicable Bar Length (cm/inch)   25/10

Sound pressure level (dB(A))   99.7

Sound power level (dB(A))   110.3

CO² (g/kW・h)   961

Vibration Front handle/Rear handle (m/s²)   3.5/4.0
